Installing

Everything the installer asks, writes and accepts as a flag. The short version is in the README.

Upgrading companion launch commands

Version 1.0.1 pins newly generated companion launch commands. Existing MCP server entries remain yours and are not silently replaced. Preview your existing selection and paths with --update-docs --dry, then apply that update after checking the plan. Unchanged managed snippets in mcp/ refresh; edited snippets are preserved and named. Compare the refreshed snippets with each client's configuration and manually replace any preserved floating package command with its catalog-pinned form. Keep unrelated server settings and credentials unchanged.

For a level 3 weekly job, also follow the generated vm/jobs/README.md migration to the separate weekly-audit.env file and reload any copied systemd unit.

Install walkthrough

This recording shows the published 0.1.x installer. Version 1.0 detects your tools and asks for one confirmation. Companions start unselected, and third-party installation instructions are printed for you to run. Re-record from the published release with bash scripts/record-demo.sh.

What a run does

The installer detects the AI binaries on your PATH, proposes a setup and shows Your stack: who does what before writing. The default flow asks exactly one question:

Write these files?
[Y/n/e]  (e to change anything above):

• Confirm: press Enter or y to write the displayed files and apply the displayed project activation changes. Existing files changed outside the rules folder get backups. n exits without writing.
• Edit: enter e, choose one setting and return to the summary. The edit menu includes activation, level, AIs, main agent, companions, paths and plans; level 3 also includes API providers. Turn activation off here or pass --no-apply.
• No detected tools: answer "Which AIs do you have access to?" first, then confirm. This path asks two questions.
• Defaults: one selected tool starts at level 1; several tools including a supported worker start at level 2, subject to each tool's minimum level. Level 3 requires an explicit choice. Companions and API providers start unselected.
• Main agent: capability ranking prefers project-rule-loading subagents, then an agent-definition surface, then a CLI with a project rules file. Ties keep selection order.
• Overrides: explicit flags take precedence and appear in the plan. Existing recorded plans and automatic-effort consent survive a rerun.

The installer never writes a secret, runs no third-party installer, and preserves existing documents by default. --force explicitly replaces them. Interactive activation updates the main agent's project rules and supported settings with backups; --yes requires --apply-snippets for those changes. The summary lists every project file it will change before confirmation.

MANIFEST.json and bin/lanes.json are machine-owned and refreshed on every run. Runtime files upgrade when their content matches the previous installed hash; edited or unverifiable copies stay and are named. --upgrade-runtime replaces runtime files only. --update-docs applies the same hash check to generated documents, preserving your edits. Docs and protocols go to --dir (default ./ai-orchestrator). Supported subagent definitions and Claude Code hook scripts go to --project (default the current directory); their locations appear in the summary.

Every non-dry install runs a compact local health check. The final What's left for you section lists remaining actions, such as sign-ins or a chat app's paste step, and says when nothing remains. The generated README.md explains activation for the selected main agent and level. Uninstall removes recorded activation changes as well as unedited managed files.

The manifest's roles assignment is refreshed on every run. If a changed assignment leaves edited documents in place, the installer names that difference: aunx route uses the current manifest while those documents retain your edits. Use --update-docs to regenerate unchanged managed documents.

Project activation

Interactive installs apply activation by default as part of the one confirmation. Turn it off with --no-apply or the edit screen. Headless --yes preserves 0.1.x behavior: add --apply-snippets to apply activation; without it, project rules and settings remain untouched.

• Rules: the catalog selects the main agent's project rules file: CLAUDE.md, AGENTS.md, GEMINI.md or QWEN.md. A block between <!-- model-orchestrator:start --> and <!-- model-orchestrator:end --> is created or replaced in place, keeping every byte outside it. Incomplete or duplicate markers are refused before writing.
• Hooks: a Claude Code main agent gets its generated hooks merged into .claude/settings.json, preserving existing keys and hooks. A command with the same arguments already present in that event is kept once. Invalid JSON exits 2, names the file and writes nothing.
• Companions: a Claude Code main agent gets selected tools registered in the project's .mcp.json when activation is enabled. Existing settings and server names stay; a conflicting server entry becomes a printed step. Other main agents retain manual registration steps because the catalog has no verified project config target for them. obsidian-tc also needs your actual configuration path. No global config is changed.
• Backups: existing files changed during application get sibling <name>.bak-YYYYMMDDTHHMMSS backups, including generated files replaced on a rerun. Each path is printed; unchanged and newly created files need no backup. Existing backups are preserved.
• Preview: --dry and --dry-run list the proposed writes and backups without changing files or running the health check. For a headless activation preview, pass --yes --apply-snippets --dry with your selection and paths.
• Manual surfaces: a chat app keeps one paste step. A main agent without a catalog-supported project rules file keeps its instruction step. --no-apply leaves the relevant rules, hook and companion merge steps in the final list.
• Removal: the manifest records the applied block and added hook and MCP entries. Uninstall removes unchanged owned entries and preserves surrounding content, existing entries and backups. Edited owned content is kept and named for review.

npx model-orchestrator --yes --level 2 --ais claude-code,codex --primary claude-code --project . --dir ./ai-orchestrator --apply-snippets

Health check and sign-in

Every non-dry install runs the existing runner's --doctor presence check automatically, with no network or prompt sent. A missing CLI is reported alongside its installation command; the installer never runs that command. --doctor --run remains an explicit live check through your own vendor sign-ins.

Sign-in status is checked only when the catalog records a reliable command. Codex uses codex login status; a confirmed session removes its sign-in from What's left for you, and a confirmed sign-out prints a direct "sign in to Codex" step. Claude Code uses claude auth status and trusts only a confirmed sign-in the same way, but never a confirmed sign-out: an author-machine probe found a working, signed-in session that still reports a JSON sign-out, so any result other than a confirmed sign-in keeps the conditional "if you have not signed in yet" step for Claude Code. Every other CLI gets that same conditional step followed by its sign-in instruction. The installer never runs a login flow.

Start a fresh agent session in the displayed project to load the installed rules. For a later presence check, use aunx cli-run --doctor, or at level 2 and up node ./ai-orchestrator/bin/cli-run.mjs --doctor with your chosen rules path.

Plans and automatic effort

State known subscription plans with --plans codex=pro-20x,agy=ultra-5x, or choose subscription plans from the edit menu. The generated guidance uses plan headroom to allocate volume only. Every catalog plan currently has an unverified model mapping, so agent definitions omit model: and use your tool's configuration. Probe the available models before dispatching work. Claude Code also honors CLAUDE_CODE_SUBAGENT_MODEL; a manual model: line can set a verified choice. Plan support for xhigh and max effort remains UNVERIFIED.

--effort-auto is explicit consent to set auto only for selected high or max headroom CLI lanes. Auto chooses medium below 4,000 prompt characters and high otherwise, never higher. An audit lane may impose its own effort floor; check its configuration. Name xhigh explicitly for security-critical or irreversible work. The default install skips plan and effort questions; choosing plans in the edit menu enables the effort choice in that same step.

The two folders every run writes to

An install has two targets, and a scripted run should set both.

--project defaults to the current directory. Home-level agent configuration is refused: a Claude Code install targeting your home folder cannot write its subagents, hooks or project settings there. Choose a project folder below your home directory and set --project explicitly. The installer prints the resolved project path in the plan and says when you left it at the default.

Rules inside the project use project-relative snippet paths, so moving the whole project preserves them. Rules outside the project use absolute paths and carry a relocation note. After moving those rules, re-run the installer or set MODEL_ORCHESTRATOR_RULES_DIR for the installed rule-reading hooks, and update your agent instruction paths. An absolute override names the new folder; a relative override is relative to CLAUDE_PROJECT_DIR. route-metrics reads no rules and keeps its home-directory log. The separately installed Claude Code plugin keeps its existing default-path lookup.

Headless installation

--yes requires both --level and --ais, giving scripted installs an explicit selection. It never prompts and applies project activation only with --apply-snippets. Detection-based inference applies to the interactive flow. All existing flags remain available, including --primary, --tools, --plans, --apis, --no-tools and --no-install.

# both targets set: docs in ./ai-orchestrator, subagents into ./my-app/.claude/agents
npx model-orchestrator --yes --level 2 --ais claude-code,codex,grok --primary claude-code \
  --dir ./ai-orchestrator --project ./my-app
# Companions default to none, including with --yes.
# Add --tools codecalc,obsidian-tc,context7 to write their guides and snippets.

npx model-orchestrator --yes --level 3 --ais claude-code,codex,agy,grok,hermes,qwen,ollama --apis anthropic,openrouter --dry   # print the plan, write nothing
npx model-orchestrator --yes --level 2 --ais claude-code,codex --project ~/my-app --dir ~/my-app/ai-orchestrator --no-tools  # subagents into ~/my-app/.claude/agents
npx model-orchestrator --yes --level 2 --ais claude-code,codex,grok --primary claude-code --dir ./ai-orchestrator --project . --update-docs   # added a lane: regenerate the docs you never edited

Upgrading from 0.1.x

Use the same project and rules folder as your existing install. Preview first:

npx model-orchestrator@1 --yes --level 2 --ais claude-code,codex --primary claude-code --project . --dir ./ai-orchestrator --update-docs --dry

• Documents: --update-docs replaces only files matching their recorded installed hashes. The former brief filename migrates to TASK_BRIEF.md when unedited. An edited legacy brief stays and is named so you can move your changes deliberately.
• Runtime: unchanged managed runtime files upgrade automatically. Use --upgrade-runtime when you intend to replace an edited runtime; it leaves document edits alone.
• Companions: existing codecalc guides and snippets stay managed. New installs select none unless you pass --tools. --uninstall still removes companion files only when unedited.
• Activation: interactive reruns apply the main agent's catalog-supported project rules and settings with backups; turn this off with --no-apply. Headless reruns require --apply-snippets for activation changes.
• Compatibility: every 0.1.x installer flag remains accepted. --no-tools and --no-install remain accepted for older scripts.
• Verification: remove --dry to apply. The health check runs automatically; start a fresh agent session to load the updated rules.

The installer writes its own files and the displayed project activation changes. Missing selected CLIs and companions appear in one Install these yourself block with official commands and links.

Uninstall

Use the same --dir and --project paths you installed with. The uninstall reads MANIFEST.json under --dir and checks every recorded path before removing any file.

# Preview the exact removals and kept files.
npx model-orchestrator --uninstall --dir ./ai-orchestrator --project ./my-app --dry
# Remove the files whose content still matches the recorded hash.
npx model-orchestrator --uninstall --dir ./ai-orchestrator --project ./my-app

• Unedited files: removed when their content hash matches the manifest.
• Edited files: kept and listed by path, with the manifest retained so you can review them.
• Applied activation: an unchanged recorded rules block and the exact hook or MCP entries added by the installer are removed. Existing entries and surrounding content stay. An edited owned entry stays and is named; the manifest remains for a later retry.
• Backups: existing project files changed during cleanup get backups. Timestamped backups stay for a reviewed restore.
• Other files: anything outside the manifest stays, including your own files in shared .claude/agents/ and .claude/hooks/ folders.
• Directories: removed only when the manifest records that the installer created them and they are empty after removal. Older manifests leave directories in place because they carry no directory ownership record.
• Manifest: removed last, only when every managed file has been removed.
• Path safety: an absolute path, traversal entry, or symlink is refused before any removal. Entries must stay inside their declared --dir or --project root.
• Global configuration: installation and uninstall refuse home-level agent rules and global agent folders such as ~/.claude and ~/.codex. Choose a project directory below your home folder for project activation.
• Missing manifest: exits 2 and names the expected MANIFEST.json path.
• Target paths: --dir and --project must match the installation paths in the manifest. A mismatch exits 2 before removal.
• Preview: --dry (or --dry-run) lists the planned removals and writes nothing.

Manually pasted activation from an older install has no ownership record, so the command prints its cleanup steps. Applied blocks use <!-- model-orchestrator:start --> and <!-- model-orchestrator:end -->. Review any retained entry or backup before changing it so later edits survive.

What gets written (level 3, everything)

The tree shows the activation alternatives. Each install writes the main agent's snippet and its supported agent set; companion files appear when selected. Paths beginning with <project>/ are relative to --project, separate from the rules folder.

ai-orchestrator/
  README.md                 start here, written for your level and your AIs
  ORCHESTRATOR.md           single-agent routing rules (level 1)
  TASK_BRIEF.md            the brief every delegation carries
  CONTEXT.md               shared facts every delegation reads
  ACCEPTANCE_CHECKS.json   executable acceptance checks
  DECISIONS.md             the decision log: Did / Why / Serves / Rejected
  protocols/                acceptance-checks · build-protocol · context-file · decision-log · deep-research · docs-then-prove · gap-analysis · memory-and-record · numbers-and-logic · propagate
  CODECALC.md  OBSIDIAN-TC.md  CONTEXT7.md  mcp/   companion-tool install docs + per-agent registration snippets (if selected)
  CLAUDE.snippet.md         rules block for CLAUDE.md (Claude Code main agent)
  settings.hooks.snippet.json  hooks for .claude/settings.json (Claude Code main agent)
  GEMINI.snippet.md         rules block for GEMINI.md (Antigravity main agent)
  AGENTS.snippet.md         rules block for AGENTS.md (Codex main agent)
  QWEN.snippet.md           rules block for QWEN.md (Qwen Code main agent)
  PASTE-INTO-YOUR-AGENT.md  paste into instructions (main agent with no project rules file)
  ROUTING.md                multi-lane decision tree (level 2+)
  TIERS.md  DELEGATION_MATRIX.md  RESEARCH_TRIAGE.md  CLI-RUN.md
  bin/cli-run.mjs  bin/lanes.json          (aunx cli-run --doctor, or node bin/cli-run.mjs --doctor)
  vm/                       gateway config, compose, box rules, privacy gates, jobs/ (level 3)

<project>/.claude/agents/  Claude Code main agent's subagent set
<project>/.claude/hooks/   route-gate.mjs, subagent-context.mjs, route-metrics.mjs (Claude Code main agent)
<project>/.agents/agents/  Antigravity main agent's custom agent set

Project commands (aunx)

Install the command with npm install -g model-orchestrator, then run these from your project. aunx without a subcommand accepts the installer flags.

aunx cli-run uses the packaged runner by default; pass --dir PATH to use that project's own installed runner under PATH/bin/ instead, and aunx prints the runner path it is using. Review check commands before running them: they execute with your shell permissions.

aunx route reads MANIFEST.json first under --dir, then under ./ai-orchestrator, then in the current folder. It reads regular JSON files of at most 1 MiB, refuses symlinks and executes no project code. A missing or invalid manifest gives the generic suggestion plus an install notice.

Installer operation

The installer creates routing instructions and activates the supported project surfaces so you can start using them from a fresh agent session.

The automatic presence check proves that configured binaries can be found. It does not prove authentication, a live response or that a new agent session loaded the rules; those checks require the corresponding vendor session.
